Toshiba Shibaura BF-13AQ 5.12" Floor Type Horizontal Boring Mill
Model:
BF13AQ
Age:
1978
Ref#:
27469
Prestige Equipment is the world's leading provider of Toshiba Shibaura BF-13AQ 5.12" Floor Type Horizontal Boring Mill & machine tools & fabricating equipment. Take a look at our wide selection of new and used Manual Floor Type Horizontal Boring Mills (HBM) for sale.
Product Specifications
View Additional Specs
Features:
✓
Spindle & Quill Travel
✓
Full Pendant Controls
✓
Digital Readouts
Product Specifications
SPECIFICATIONS:
Spindle Diameter
5.12"
Quill Diameter
7.09"
Milling Spindle Sleeve Diameter
13.4"
Vertical Travel Y-Axis
98.42"
Column Travel, X-Axis
236.22"
Spindle Travel, Z-Axis
35.4"
Quill Travel, Z-2 Axis
13.78"
Combined Spindle & Quill Travel
35.4"
Spindle Taper
#50
Spindle Speeds (24)
4-800 RPM
Feeds (16)
.0018-.315 IPR
Electrics
230/460/3/60
Approx Machine Foorprint
322" x 135"
Machine Height
201"
Equipped With:
Full Pendant Controls
Operator's Platform
3-Axis Digital Readouts
Power Draw Bar
Hardened and Ground Ways on All Axes
Sliding Steel Way Covers on X-Axis
30 HP Spindle Drive Motor
NOTE:
Inspect In Our Philadelphia PA Warehouse
Offer Includes Disassembly and Loading to Trucks
Packing For Export is Additional Cost
Features:
✓
Spindle & Quill Travel
✓
Full Pendant Controls
✓
Digital Readouts
