16" SXP Seamless Pipe Annealing Furnace
Model:
Walking Beam Annealing Furnace
Age:
2016
Ref#:
44367
Prestige Equipment is the world's leading provider of 16" SXP Seamless Pipe Annealing Furnace & machine tools & fabricating equipment. Take a look at our wide selection of new and used Annealing Furnaces for sale.
Product Specifications
View Additional Specs
Features:
✓
Hydraulic Walking Beam Movement
✓
Horizontally & Vertically Adjusted Walking Beams
✓
Electromechanically Controlled Entry & Exit Doors
✓
Infeed Roller Belts
✓
Outfeed Conveyance
Product Specifications
SPECIFICATION:
Pipe Capacity Range, Stainless
3.8" - 16"
Pipe Length Capacity
108" - 564"
Maximum Furnace Temp., Fahrenheit
2100°
Recuperation Burners, Qty.
8 Left /7 Right
Air Compression System, 2 Zone
100 MBar
Max Throughput
48 Pipes/ 12 Hour
Distance Between Inside Walking Beams . 9.84"
Interior Moveable Beams
10
Walking Beam Lift Distance
3.14" - 3.93"
Walking Beam Transportation
5.90" Horizontally
Roller Belt Speed
3937 IPM
Equipped With:
Hydraulic Walking Beam Movement (Installed Under Platform)
Horizontally & Vertically Adjusted Walking Beams
Electromechanically Controlled Entry & Exit Doors
Infeed Roller Belts
Outfeed Conveyance with Quench Tank
Ticklers
Rolls
Spare Support Parts
NOTE:
See Process Description For Additional Information
Features:
✓
Hydraulic Walking Beam Movement
✓
Horizontally & Vertically Adjusted Walking Beams
✓
Electromechanically Controlled Entry & Exit Doors
✓
Infeed Roller Belts
✓
Outfeed Conveyance
