Poreba TCF 200/8M 78.74" x 314.96" CNC Lathe, Brand New
Model:
TCF 200 x 8M
Age:
2020
Ref#:
30732
Prestige Equipment is the world's leading provider of Poreba TCF 200/8M 78.74" x 314.96" CNC Lathe, Brand New & machine tools & fabricating equipment. Take a look at our wide selection of new and used Manual & CNC Flat Bed Lathes for sale.
Product Specifications
Features:
✓
Siemens Sinumerik sl CNC Controls with Siemens RSC
✓
Marpos tool measurement system
✓
Sauter 4-position tool turret with Capto C6
✓
(1) 31.49" Roller Type Steady rest
✓
(1) 7.87" x 118.11" Boring Bar
✓
OD Grinding Attachment
✓
Internal Grinding Attachment
✓
Coolant System
✓
Hardened Steel Bedways
Product Specifications
CAPACITY:
Maximum Swing Over Bedways
78.74"
Maximum Swing Over Carriage
62.99"
Distance Between Centers
314.96"
Height of Centers Over Flat Way
39.37"
Spindle Bore Diameter
5.9"
Width of Bed
59.05"
Height of Bed
23.62"
Spindle Speeds
3
Chuck Size, Option 1
78.74"
Max/Min Clamping Dia
70.86" 9.84"
Speeds, 3 Ranges
0.3-150 RPM
Chuck Size, Option 2
49.21"
Max/Min Clamping
41.33" 9.84"
Speed Ranges I
0.5-250 RPM
WEIGHT CAPACITY BETWEEN CENTERS:
Without Steady Rests
66,000 Lbs
With One Steady Rest
77,000 Lbs
With Two Steady Rests
88,000 Lbs
SADDLE:
Maximum Cutting Force
100000 N
Longitudinal Feeds, Stepless
.003937 IPR to 15.748 IPR
Cross Feeds, Stepless
.003937 IPR to 7.874 IPR
Longitudinal Saddle Rapid Traverse
59.05 IPM
Cross Saddle Rapid Traverse
98.42 IPM
Cross Saddle Rapid Traverse Torque
66 Nm
TAILSTOCK:
Tailstock Quill Diameter
11.02"
Tailstock Quill Travel
12"
Quill Rapid Travel
11.81 IPM
Tailstock Rapid Travel
59.05 IPM
Tailstock Rapid Travel Motor
2.95 HP
Tailstock Quill Motor
2.95 HP
Equipped With:
Siemens 840D sl CNC Control with Siemens RSC
Marpos tool measurement system
Sauter 4-position tool turret with Capto C6
78.74" Diameter 4-Jaw Chuck (A1-20)
31.49" Roller Type Steady rest
(1) 7.87" x 118.11" Boring Bar
OD Grinding Attachment
Internal Grinding Attachment
Air Conditioned Control Cabinet
60 Degree Dead Center
Coolant System
Hardened Steel Bedways
Heavy Duty Meehanite Castings
Hydraulic Tailstock
One Set Foundation and Levelling Blocks
Complete Operators Manual
95.21 HP Main Drive Motor
NOTE:
Immediate Delivery!
3-Way Bed Allows Carriage to Pass Tailstock and Steady Rest
Features:
✓
Siemens Sinumerik sl CNC Controls with Siemens RSC
✓
Marpos tool measurement system
✓
Sauter 4-position tool turret with Capto C6
✓
(1) 31.49" Roller Type Steady rest
✓
(1) 7.87" x 118.11" Boring Bar
✓
OD Grinding Attachment
✓
Internal Grinding Attachment
✓
Coolant System
✓
Hardened Steel Bedways
