Baykal APHS 2100x300 330 Ton x 2083 MM 4-Axis CNC Press Brake
Model:
APHS 2100x300
Age:
2010
Ref#:
31450
Prestige Equipment is the world's leading provider of Baykal APHS 2100x300 330 Ton x 2083 MM 4-Axis CNC Press Brake & machine tools & fabricating equipment. Take a look at our wide selection of new and used Hydraulic Press Brakes for sale.
Product Specifications
Features:
✓
Delem DA51 4-Axis CNC Control
✓
Programmable Ram Depth (Y1,Y2)
✓
2-Axis CNC Back Gauge (X,R,)
✓
Mechanical Crowning System
✓
American Style Ram Clamps
✓
(2) Movable Front Gauge Support Arms
✓
Electric Foot Switch Control
✓
Pedestal Palm Button Control
✓
AKAS Light Curtains
Product Specifications
SPECIFICATION:
Maximum Tonnage Capacity
330 Ton
Overall Length Of Bed & Ram
2100 MM
Distance Between Housings
1575 MM
Open Height
475 MM
Throat Depth
410 MM
Stroke Length
318 MM
Approach Speed
5334 MM/MIN
Bending Speed
564 MM/MIN
Return Speed
4801 MM/MIN
Main Motor
22 KW
Approximate Dimensions (L x W x H)..... 114” X 90.5” X 123”
114” X 90.5” X 123”
Approximate Shipping Weight
14601 KG .
Equipped With:
Delem DA51 4-Axis CNC Control
Programmable Ram Depth (Y1,Y2)
2-Axis CNC Back Gauge (X,R,)
Mechanical Crowning System
American Style Ram Clamps
(2) Movable Front Gauge Support Arms
Electric Foot Switch Control
Pedestal Palm Button Control
AKAS Light Curtains
NOTE:
Inspect in Plant Under Power
Features:
✓
Delem DA51 4-Axis CNC Control
✓
Programmable Ram Depth (Y1,Y2)
✓
2-Axis CNC Back Gauge (X,R,)
✓
Mechanical Crowning System
✓
American Style Ram Clamps
✓
(2) Movable Front Gauge Support Arms
✓
Electric Foot Switch Control
✓
Pedestal Palm Button Control
✓
AKAS Light Curtains
