Giddings & Lewis RT1600 CNC Boring Mill
Model:
RT1600
Age:
2006
Ref#:
43664
Prestige Equipment is the world's leading provider of Giddings & Lewis RT1600 CNC Boring Mill & machine tools & fabricating equipment. Take a look at our wide selection of new and used CNC Table Type Horizontal Boring Mills (HBM) for sale.
Product Specifications
Features:
✓
Fanuc 310i-High Performance CNC Control w/Machine Control Panel
✓
Built In Full B-Axis Rotary Table
✓
120 Station Automatic Tool Changer
✓
Thru Spindle Coolant
Product Specifications
SPECIFICATIONS:
Spindle Diameter
155 MM
Taper In Spindle
ANSI B5.50 R.K
X-Axis Table Travel
4801 MM
Y-Axis Vertical Head Travel
3599 MM
Y-Axis Travel Above Table
3465 MM
W-Axis Table Infeed Travel
78.7
Z-Axis Spindle Travel
1250 MM
Table Size, Built-In Rotary
1600 MM x 2489 MM
Table Rotation, B-Axis
.001 degrees
Table Load Capacity
24993 KG
Spindle Speeds
1-3500 RPM
Spindle Speed Ranges
4
Spindle Motor
37 KW /55 KW
Equipped With:
Fanuc 310i High Performance CNC Control with Machine Control Panel
120 Position Tool Changer
Thru-Spindle Programmable Coolant
Renishaw RMP60 Probe With Radio Transmission
4-Speed Headstock
Rigid Tapping
Remote Manual Jog Pendant
Linear Scale Feedback, X, Y, & W Axes
Servo Motor Encoded, Z-Axis
Direct Feedback Encoder, B-Axis
89 MM Floppy Drive
FANUC CNC CONTROL EQUIPPED WITH:
Fanuc 310i High Performance CNC
Rigid Tapping
High Level Programming Capability (variables and
parameters)
Remote hand held pendant with MPG
Interior lighting for control cabinet
Rigid Tapping
High Level Programming Capability (variables and
parameters)
Remote hand held pendant with MPG
Interior lighting for control cabinet
Coordinate System Rotation (J893)
Work Coordinate System (J894)
48 Additional Work Piece Coordinate Systems (J895)
Remote Pendant with MPG (T014)
Fixed Cycles G7x-G8x Series Cycles (J890)
Rigid Tapping - G74, G84 (J828)
Tool Retract and Return w/ret for Rigid Tapping (J823, J664)
Custom Macros & Variables - 600 Total Commom (J873,J887)
Programmable Inch / Metric (J876)
Programmable Mirror Image (J880)
Programmable Data Input (J872)
Stored Pitch Error Compensation (J841)
Stored Limit Check before Movement (J749)
5120 Meters of Part Program Storage (J948)
1000 Stored Part Programs (J953)
Background Editing (J956)
Bell Shaped Acc/Dec after Interp. for Cutting Feed (J829)
Helical Interpolation (J819)
Distance Coded Linear Scale (J670)
Dual Position Feedback (J704)
Tool Length Measurement (J938)
Stored Limit Check Before Movement (J749)
Cylindrical Interpolation A 70.2.011 - G7.1 (J816)
Rotary Table Fixture Compensation - G54.2 (S728)
Inverse Time Feed - G93 (J715)
Manual Handle Interruption (J837)
Program Restart (J838)
Remote Handy Operator Station
Software for control of CH facing heads and prog. boring bars
NOTES:
Inspect Under Power Prior To Removal From Ohio Plant
