Toshiba BP-130.P40 130 MM CNC Table Type Horizontal Boring Mill
Model:
BP-130.P40
Age:
2000
Ref#:
31711
Prestige Equipment is the world's leading provider of Toshiba BP-130.P40 130 MM CNC Table Type Horizontal Boring Mill & machine tools & fabricating equipment. Take a look at our wide selection of new and used CNC Table Type Horizontal Boring Mills (HBM) for sale.
Product Specifications
Features:
✓
Tosnuc 888 CNC Control
✓
1778 MM x 3937 MM T-Slotted Table
✓
55,000 Lb Weight Capacity
✓
Infeeding Column
✓
Through Spindle Coolant
Product Specifications
Serial Number
130291
CAPACITY:
Spindle Diameter
130 MM
Milling Spindle Diameter
250 MM
Spindle Taper
CAT #50
Vertical Travel, Y-Axis
2286 MM
Table Cross Travel, X-Axis
4064 MM
Spindle Travel, Z-Axis
711 MM
Column Travel, W-Axis
1524 MM
Distance, Table to Spindle Center
102 MM -2388 MM
Table Size
1778 MM X 3937 MM
Spindle Speeds
10-2500 RPM
Table Weight Capacity
24948 KG .
Rapid Traverse, X, Y, & Z Axes
10000 MM/MIN
Rapid Traverse, W-Axis
4999 MM/MIN
Feedrate, X, Y, & Z Axes
5995 MM/MIN
Feedrate, W-Axis
4979 MM/MIN
Machine Height
4928 MM
Floor Space
394”x 5842 MM
Machine Weight
40823 KG .
Equipped With:
Tosnuc 888 CNC Controls
Pendant Control
Thru Spindle Coolant
Hardened & Ground Box Ways
Telescoping Steel Way Covers
Chip Conveyor
22 KW /30 KW Spindle Drive
Features:
✓
Tosnuc 888 CNC Control
✓
1778 MM x 3937 MM T-Slotted Table
✓
55,000 Lb Weight Capacity
✓
Infeeding Column
✓
Through Spindle Coolant
