HARTFORD HSA-836EAY 5-Face Double Column Bridge Mill
Model:
HSA-836EAY
Age:
2017
Ref#:
32563
Prestige Equipment is the world's leading provider of HARTFORD HSA-836EAY 5-Face Double Column Bridge Mill & machine tools & fabricating equipment. Take a look at our wide selection of new and used CNC Bridge Type Vertical Machining Centers (VMC) for sale.
Product Specifications
Features:
✓
Fanuc OiMF CNC Control
✓
32 Station Automatic Tool Changer
✓
Automatic Universal Head (A/C Axis Auto 5 Degree Indexing)
✓
Extension Head (4,000 RPM)
✓
X/Y/Z Roller Linear Guide Ways
✓
X/Y/Z Linear Scales
Product Specifications
SPECIFICATIONS:
X-Axis, Table Travel
8000 MM
Y-Axis, Spindle Head Travel
5000 MM
Z-Axis, Vertical Travel
1200 MM
Distance Between Columns
4200 MM
Height Between Table And Spidle
1310 MM
Distance from Spindle to Center Column
450 MM
Table Size
8100 MM x 3500 MM
Table Load Capacity
29937 KG
Spindle Taper
BT 50
Spindle Speeds (Gear Type)
6,000 RPM
Spindle Motor
22 KW /19 KW
Cutting Feed Rate (X-Axis)
6000 MM/MIN
Cutting Feed Rate (Y/Z Axis)
10000 MM/MIN
Rapid Traverse (X-Axis)
8000 MM/MIN
Rapid Traverse (Y-Axis)
16000 MM/MIN
Rapid Traverse (Z-Axis)
15000 MM/MIN
Approximate Floor Space
8650 MM x 2100 MM
Approximate Machine Weight
74344 KG .
Equipped With:
Fanuc OiMF CNC Control
32 Station Automatic Tool Changer
Automatic Universal Head (A/C Axis Auto 5 Degree Indexing)
Extensions Head (4,000 RPM)
X/Y/Z Roller Linear Guide Ways
X/Y/Z Linear Scales
Centralized Automatic Lubrication System
Spindle Air Blow Device
Spindle Oil temperature Cooler
Spindle Oil Cooler
Oil Skimmer
Chip Conveyor
Features:
✓
Fanuc OiMF CNC Control
✓
32 Station Automatic Tool Changer
✓
Automatic Universal Head (A/C Axis Auto 5 Degree Indexing)
✓
Extension Head (4,000 RPM)
✓
X/Y/Z Roller Linear Guide Ways
✓
X/Y/Z Linear Scales
